Product features: hydraulic
Type: proportional valve
Material: cast iron
Model:4WRA6W30-2X/G24K4/V
Brand:Rexroth
Type (channel position): through type
Connection form: threaded
Drive mode: electromagnetic
Scope of application: hydraulic
Applicable medium: oil
Applicable temperature:30ºC
Nominal pressure:200MPa

Structure:Vertical
Display mode: pointer type

Product Description

Two-position four-way and three-position four-way proportional directional valves are used as direct-acting devices in valve plate design.

They are operated by means of proportional solenoids with centering threads and removable coils.

The coil is controlled by external control electronics.

Setup:

The basic components of the valve include:

Housing with connecting surfaces

control spool with compression spring
Coil with centering thread

Function:

When the coil is de-energized, the compression spring keeps the control spool in the center position -

Direct operation of the control spool by energizing a proportional solenoid, e.g. control coil "b".

Moves the control spool to the left in proportion to the electrical input signal.

Connection from P to A and from B to T by means of a throttling cross-section with progressive fluid characteristics

Closing coil

The control spool is returned to the center position by the compression spring.
